The Ford Bronco Sport is a compact crossover SUV designed for a balance of on-road commuting and off-road capability. It is built on a unibody platform derived from the Ford Escape but features extensive modifications to its chassis, suspension, and drivetrain to deliver superior performance on challenging terrain. The vehicle is engineered to provide a robust, trail-ready option within the compact SUV segment.

Core Technical Specifications

The Bronco Sport is available with two primary EcoBoost engine options, both paired exclusively with an 8-speed automatic transmission and standard 4×4 capability across all trims.

Powertrain Options and Performance

Transmission: All models utilize an 8-speed SelectShift® automatic transmission.

Drivetrain: A permanent 4×4 (Four-Wheel Drive) system is standard on every Bronco Sport model.

Dimensions and Vehicle Mass

Vehicle dimensions vary slightly based on the equipped engine and suspension setup.

Off-Road Capability and Drivetrain Technology

The Bronco Sport’s off-road prowess is defined by its suspension, drivetrain systems, and selectable traction modes.

G.O.A.T. Modes® (Goes Over Any Type of Terrain)

All Bronco Sport models feature the Terrain Management System, which allows the driver to optimize vehicle performance for specific surface conditions. This system adjusts the throttle mapping, steering response, transmission shift points, and 4×4 torque distribution.

• Standard 5 Modes (1.5L Engine): Normal, ECO, Sport, Slippery, Sand.
• Available 7 Modes (2.0L Engine/Badlands): Adds Mud/Ruts and Rock Crawl to the standard modes, offering greater low-speed control for severe terrain.

Advanced 4×4 System

Models equipped with the 2.0L EcoBoost engine feature the Advanced 4×4 with Twin-Clutch Rear-Drive Unit. This system significantly enhances off-road traction:

• Torque Vectoring: Unlike traditional AWD systems, the twin-clutch unit can mechanically divert virtually all available rear axle torque (up to 100%) to a single rear wheel if needed.
• Traction Loss: This function maintains forward momentum even if the opposite wheel or the entire front axle loses traction, making it critical for crossing uneven, technical trails.

Chassis and Suspension Enhancements

• Skid Plates: Available steel bash plates (skid plates) protect the vehicle’s underside, including the fuel tank, engine, and transfer case, from impact damage when traversing rocky obstacles.
• Dampers: The 2.0L Badlands trim includes off-road-tuned suspension with unique springs and available Bilstein rear shock absorbers for increased endurance and better absorption of extreme trail impacts.
• Recovery Points: Select trims feature four recovery underhooks (two front, two rear) suitable for vehicle extraction.

Trail Technology

• Ford Trail Control: Functions as a low-speed cruise control system for off-roading. The driver sets a low speed, and the system automatically manages acceleration and braking on rough or slippery surfaces, allowing the driver to focus exclusively on steering inputs.
• 1-Pedal Driving: This feature integrates with Trail Control and allows the driver to modulate both speed and braking using only the accelerator pedal. Releasing the accelerator applies the brakes automatically, simplifying low-speed rock crawling.
• 360-Degree Camera: An available camera system provides a virtual bird’s-eye view, which is especially useful for navigating tight trails and crowded areas. This system includes a Trail View function when in G.O.A.T. modes, displaying width-accurate tire overlays to aid in wheel placement.

Interior Features and Utility

The interior of the Bronco Sport is designed to balance rugged durability with modern connectivity and convenience.

Infotainment and Connectivity

• Infotainment: The center console features an 8.0-inch touchscreen running the SYNC® 3 or SYNC® 4 infotainment system.
• Instrument Panel: A customizable, high-resolution 12.3-inch Digital Instrument Panel is available to display crucial information, including vehicle status and real-time off-road data.
• Integration: The system is compatible with both Apple CarPlay® and Android Auto™ via wireless connection.
• Sound: An available B&O® Sound System by Bang & Olufsen® includes 10 speakers and a subwoofer.
• Power Access: The vehicle includes a wireless charging pad and multiple USB ports throughout the cabin (typically 4: 2 front, 2 rear) for device charging. Certain trims also feature a dash-mounted accessory tray with dedicated USB ports for easy installation of aftermarket electronics like dash cameras.

Utility and Durability

• Cargo Area: The cargo hold offers versatility, including available features such as:

• A slide-out table that functions as a workspace or meal prep surface.
• Rubberized flooring and cargo matting designed for easy cleaning after outdoor activities.
• Interior tie-downs and the ability to stand two 27.5-inch mountain bikes upright (with the rear seats folded).

• Seating: Seating options range from durable, easy-to-clean cloth to premium-trimmed seats and available specialized materials like Ombre Stitching.
• Aftermarket Integration: Four available pre-wired auxiliary switches are integrated into the overhead console, simplifying the installation and wiring of aftermarket accessories such as winches, auxiliary lights, and air compressors.
